Hot Finish Square Hollow Section

Our Product

HOLLOW SECTION

Products

Carbon Steel S355J0H Hot Finish Square Hollow Section Suppliers, EN10210 S355J0H MS Hot Finished Square Tube Stockists in India, Hot Finish EN 10210 S355J0H SHS Pipe in Mumbai.

Hot Finished EN10210 S355J0H Square Box Sections, S355J0H CS Hot Finish Square Pipes Distributors, BS EN 10210 S355J0H Hot Finish SHS Tubes, Hot Rolled S355J0H Mild Steel Square Hollow Section Exporters in Mumbai, India.

Ranflex Metals is one of the best manufacturers, exporter, and stockiest of EN 10210 S355J0H Mild Steel Hot Finished Square Hollow Sections. These EN 10210 Hot Finished S355J0H Square Hollow Section Pipes usually contains 1.60% manganese, silicon content up to 0.55%, phosphorus and sulfur content up to 0.35%, and 0.22% carbon content. Its length ranges from 6000mm to 18000mm, and its wall thickness starts from 1.8mm to 14.27mm. These Grade S355J0H Hot Finished Welded Structural Square Hollow Sections are available in different sizes and shapes. However, one can get these hollow sections in their desired shapes and sizes.

Hot Finished EN 10210 S355J0H Square Hollow Section Pipes have high corrosion resistance to high-temperature environment and it is mostly used at highly elevated temperatures. It is also highly resistant to general corrosion. These Hot Finished EN 10210 S355J0H Square Box Sections possesses high tensile strength and yield strength. It is manufactured following international quality standards. These EN 10210 S55J0H Mild Steel Hot Finished Square Tubes have the best corrosion resistance to oxidation corrosion.

Hot Finished EN 10210 S355J0H Square Hollow Section is mostly used in the marine industry and seawater equipment. It is also used in machinery parts, screws, shafts, and fasteners. Hot Finished EN 10210 S355J0H Square Hollow Section ERW Pipes are mostly used in heat exchangers and condensers. Hot Finished EN 10210 S355J0H Square Hollow Sections can be used in food processing units and food packaging units.

Hot Finish EN 10210 S355J0H SHS Specification

Standard	BS EN 10210 - Hot finished structural hollow sections of non-alloy and fine grain steels
Grade	S355J0H
SHS (Square Hollow Sections) Sizes	2020mm-400400mm
Wall Thickness	0.5mm - 25mm
Length	6000-14000 mm
Type	Seamless/ Welded / ERW
Dimensional Tolerances	Thickness (All sizes +/- 10%)
Packing	In bundles, Anticorrosion heat preservation, Varnish coating, Ends can be bevelled or square cut, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Protection	Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized

Hot Finish EN 10210 S355J0H SHS Properties

Steel Grade		% by mass maximum
Steel Name	Steel Number	C specified thickness (mm)		Si	Mn	P	S	N
		<_40	> 40 <_ 120
S355J0H	1.0547	0.22	0.22	-	1.50	0.035	0.035	0.009

Steel Grade		Minimum yield strength eH Mpa						Minimum tensile strength Rm Mpa
Steel Name	Steel Number	Specified thickness in mm						Specified thickness in mm
Steel Name	Steel Number	<_16	>16 <_40	>40 <_63	>63 <_ 80	>80 <_100	>100 <_120	<_3	>3 <_100	>100 <_ 120
S355J0H	1.0547	355	345	335	325	315	295	510-680	470-630	450-600

HxB – Height x Base

Wt – Wall thickness

Kg/m – Kilos per linear metre

Er – External radius

L – Standard bar length

Size mm	kg/m	Size mm	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192

Hot Finish EN 10210 S355J0H SHS Services

Packaging

We Hollow Section Ensure the best quality of Packing , because its play important role especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put extraordinary concern regarding packaging.

Testings (Destructive, Non Destructive)

Application Industries
